Precise drawings for every claim, remodel or fit out
Use the PLANIX camera system to capture thousands of measurements per scan, or use our Commercial Capture Services to do the work for you.
Our drawings come in various formats including CAD 3D models, ESX or DWG with the option to include elevation drawings, roof plans and reflexed ceiling plans. With iGUIDE, you get detailed and reliable data that helps you turn your vision into reality with confidence.
Explore our iGUIDE
Drawing Packages
iGUIDE 3D CAD Package
3D Virtual Walkthrough • CAD Floor Plan • 3D Model • Plotted PDF • Roof Plan • Exterior Elevation Drawing
Unlock a property's full potential. This package pairs iGUIDE's immersive experience with 2D CAD (DWG) and 3D Model (Revit) deliverables, detailed Plotted PDFs, plus a Roof Plan and Exterior Elevation Drawing to provide comprehensive documentation of your property.
Estimated delivery: 5-10 business days¹
Add-on: Reflected Ceiling Plan
iGUIDE 2D CAD Package
3D Virtual Walkthrough • CAD Floor Plan • Plotted PDF
Get the complete picture. This bundle combines iGUIDE's immersive tours with editable CAD Floor Plans (DWG files) and detailed Plotted PDFs for comprehensive property documentation and a jumpstart on your design process.
Estimated delivery: 1-5 business days¹
Add-on: Reflected Ceiling Plan
iGUIDE Add-ons
Enhance your project with additional detail
- Reflected Ceiling Plan (available with both packages)
- Roof Plan (included with the ‘3D CAD Package’)
- Elevation Drawings (included with the ‘3D CAD Package’)
¹Delivery time is dependent on property size and complexity and may exceed 48 hours. Excluding Sundays, holidays, and outside office hours (Mon – Fri, 9am – 5pm EST).
Blueprint your success with iGUIDE
iGUIDE delivers features developed to provide a head start when creating as-built floor plans and 3D models to meet your remodel, construction, commercial design or insurance claim project.
Diverse window types are available
This window collection includes casement, double hung, hopper or awning, jalousie, fixed and sliding types, each offering unique features.
A LOD (level of development) of 200
Interior wall thicknesses are set to North American standards² and exterior spaces are included (patios, decks, porches, etc.).
²Dimensional lumber increments.
AIA (American Institute of Architects) standard layers
Annotations include labels, area totals, objects, dimensions, etc. (iGUIDE Premium only)
Start using iGUIDE today!
iGUIDE DWG Add-on
DWG Floor Plans can be added to any standard or premium iGUIDE. Simply request the DWG Add-on when creating an iGUIDE Standard or Premium and your DWG file will be delivered in 48 hours or less.³
iGUIDE Standard: DWG Floor Plan
Includes features such as various window types, interior wall thicknesses set to North American standards, vertical floor-to-floor alignment and a LOD of 200.
iGUIDE Premium: DWG Floor Plan
It’s taking what you love in the iGUIDE Standard DWG and enhancing it with additional details including annotations such as labels, area totals, objects and dimensions.
³DWG Floor Plan delivery time is dependent on property size and complexity and may exceed 48 hours. Excluding Sundays, holidays and outside office hours (Mon – Fri, 9am – 5pm EST).
iGUIDE RVT Add-on
Significantly reducing design process timelines, the iGUIDE RVT Add-on⁴ can be requested with any premium iGUIDE.
- 3D model built from lidar data with vertical floor-to-floor alignment
- 2D DXF, Point Cloud data, DWG Floor Plan, realistic rendering and 3D virtual walkthrough
- Complex ceilings, window types, structural elements and features
- Annotations with labels, area totals, objects, dimensions, etc.
- Exterior spaces: porches, patios, decks, etc.
⁴RVT model delivery time is dependent on property size & complexity which may exceed 72 hours. Excluding Saturdays & Sundays, holidays and outside office hours (Mon – Fri, 9am – 5pm EST). Only available in North America.
iGUIDE Add-ons work with programs
you’re already using
iGUIDE ESX Floor Plans
Find the option that fits your delivery schedule and specific needs.
Instant Sketch⁵
When you need to react quickly, an ESX file is delivered in minutes via Verisk Xactimate.
- Site documentation
- Lidar laser-accurate measurements
- Virtual walkthrough
Begin the claim before you leave the property.
Standard iGUIDE: ESX
Capture structural property damage. A comprehensive ESX file is delivered within 24 hours.⁶
- Multi-floor capture
- Detailed annotations and tagging
- Structural features include walls, windows, doors and stairs
A complete documentation solution for more in-depth assessments.
Premium iGUIDE: ESX
Captures structural and asset damage. A detailed ESX file is delivered within 24 hours.⁶
All features are included in the standard ESX file, cabinet components and complex ceilings.
Comprehensive documentation of properties impacted by floods, water damage and limited fire damage.
If you request an Instant Sketch but require additional detail, upgrade to iGUIDE Standard or Premium at any time.
⁵iGUIDE Instant Sketch is currently in BETA. The machine-generated sketch quality relies on the input data the camera operator provides. Although iGUIDE and Verisk aim for typical file delivery in Xactimate within minutes, this timeframe may vary depending on load factors, such as after a catastrophic loss event. iGUIDE Instant Sketch is limited to properties no greater than 5,000 sq ft and projects with no more than 75 scans.
⁶ESX files are delivered within one business day, excluding holidays and outside office hours (Mon – Fri, 9am – 5pm EST).
Connect with an
iGUIDE Project Manager
Frequently Asked Questions
The time it takes to receive an iGUIDE DWG floor plan varies based on the size and complexity of the property. Generally, the turnaround time ranges from 24 to 48 hours, with larger or more intricate properties potentially requiring a bit longer.
Yes. You are required to order an iGUIDE Standard or Premium to get a DWG Floor Plan.
iGUIDE DWG Floor Plans are a head start on creating more complex drawings. They can save you a great amount of time and money in the lead-up to creating your custom drawing by greatly reducing the time it takes to measure a property and convert it into a usable CAD file.
Acceptable tolerance for wall thicknesses is + or – 1/2”. This information is based upon the maximum dimensions of each room and will have an effect on room dimensions. Room dimensions can also vary. Acceptable tolerance is + or – 1/4”.
Trusted by industry professionals
I was introduced to iGUIDE by a restoration contractor. The value is to me for measurements, photo documentation and post-inspection estimate preparation. It’s great to share with team members.
We have five people working in-house. We flipped the switch to utilizing the technology and we’re doing three to four times the amount of work with the same people.
They [iGUIDE] are great and the Xactimate ESX file is incredible. The amount of time saved on return trips to measure is huge savings. The camera will pay for itself. To be able to have a full sketch 24 hours later is great.
By using my iGUIDE I don't have to worry if a draftsman can show up to measure or is sick and can't draft the plans. With the iGUIDE, I can take my photos, easily upload to the website and very quickly get the 3D tour and CAD file. The quick turnaround allows me to move fast and design quicker than before. I have gotten plans back to clients in days, not weeks!
This product amazes me every time I use it. It works so flawlessly and it's such a joy to have and use for my work. I shot a 53,000 sq ft office space and although it took a while, it was so easy and took little effort on my part aside from moving around the 5-story building.
Thanks for all the help getting us started, I love the product! It's changed our remodelling workflows in just the first few weeks.
